产品说明/Product description
导体/Conductor: 导体采用多股绞合裸铜或镀锡铜绞合
Conductors are stranded by multiple strands of bare copper or tin-plated copper
绝缘体/Insulator:SR-PVC
温度范围/temperature range:-40℃~ +80℃
额定电压/Rated voltage: 300V
执行标准/Implementation criteria: UL758、UL1581 CSA C22.2
型号/Mode |
规格/Specifications |
铜丝根数/标称直径 |
成品外径OD |
电缆重量km/kg |
UL 1061 |
28AWG |
7/0.127 |
0.9 |
1.4 |
UL 1061 |
26AWG |
7/0.16 |
1.0 |
1.9 |
UL 1061 |
24AWG |
11/0.16 |
1.13 |
2.8 |
UL 1061 |
22AWG |
17/0.16 |
1.28 |
4.0 |
UL 1061 |
20AWG |
26/0.16 |
1.5 |
6.4 |
UL 1061 |
18AWG |
41/0.16 |
1.8 |
9.8 |
UL 1061 |
16AWG |
65/0.16 |
2.1 |
14. |
